| Surge arrester (2x2-pole) for measurement and control technology. | |
| Surge protective device according to DIN EN 61643-21, designed as coarse and fine protection for earth-potential free signal circuits. | |
| Max. continuous voltage Uc: 6 V - / 4.5 V ~ | |
| Lightning impulse current Iimp: 5 kA (10/350 µs) | |
| Nominal discharge current In: 20 kA (8/20 µs) | |
| Voltage protection level line/line Up: < 15 V | |
| Nominal current: 0.75 A | |
| Dimensions: 1 mod. | |
| Mounting on rail 35 mm according to DIN EN 60715 | |
| Type: P-2 SQ 5
