| according to EN 62561-1 for secure connection of different materials to saddles. | |
| Fit: Ø 8-10 mm | |
| Bead thicknesses: up to 8 mm | |
| Material intermediate plate: Bimetal aluminium/copper | |
| Screws: [2x] Cylinder head screw M6, stainless steel V2A/copper plated | |
| [2x] Cylinder head screw M6, stainless steel V2A | |
| The established clamping-system by J.Pröpster. It is a reasonably priced and practical solution for a proper connection between different materials. | |
| Benefits: | |
| • Simplified handling - no coping with self-made washers | |
| • Non-corrosive connections between wires made of different materials (e.g. steel, aluminium) | |
|
• Corrosion-free connections between copper wires and earth lead-in rods, test joints, skylights, metal constructions For more detailed information, you can review the page in the link below. |
|
